DCV20-2OT
Short Description:
Model DCV20 series valves with middle-high pressure monoblock construction is developed based on Europe technology. ♦ Inner check valve: The check valve inside the valve body is to insure the hydraulic oil not to be returned. ♦ Inner relief valve: The relief valve inside the valve body is able to adjust the hydraulic system working pressure. ♦ Oil way: Parallel circuit. ♦ Control Way: Manual control. ♦ Valve construction: monoblock construction, 1-6 levers. ♦ Spool Function: O,Y, P,A. Model C...
Product Detail
Product Tags
Model DCV20 series valves with middle-high pressure monoblock construction is developed based on Europe technology.
♦ Inner check valve: The check valve inside the valve body is to insure the hydraulic oil not to be returned.
♦ Inner relief valve: The relief valve inside the valve body is able to adjust the hydraulic system working pressure.
♦ Oil way: Parallel circuit.
♦ Control Way: Manual control.
♦ Valve construction: monoblock construction, 1-6 levers.
♦ Spool Function: O,Y, P,A.
Model Code
DCV20 F-OT T(Spring Return) ; W(DetentControl)
T(Spool Function) O、A、Y
TNom.Pressure ( MPa) :E16、F20
Nom. Flow Rate:20 (L/min )
Monoblock Directional Control Valves
Parameters
|
(MPa) Nom. Pressure |
(MPa) Max. Pressure |
(L/ min) Nom. Flow rate |
(L/min) Max. Flow rate |
(MPa) Back Pressure |
hydraulic oil | ||
|
(°c) Tem.rang |
(mm2/S ) Visc.rang |
（5m) filtrating accuracy |
|||||
|
16 |
31.5 |
20 |
20 |
W1 |
-20〜+80 |
10-400 |
W10 |
