CDB15
Short Description:
CDB-※15 series sectional directional hydraulic control valve is a kind of combination valve assembled with check valve, inlet slice, outlet slice and working slices. This valve has such characteristics as compact structure, high working pressure, good performance, high reliability, etc The circuit is parallel connection. There are many spool functions for option. The positioning and returning modes of the valve include spring returning and detent control. There is a check valve inside the val...
Product Detail
Product Tags
CDB-※15 series sectional directional hydraulic control valve is a kind of combination valve assembled with check valve, inlet slice, outlet slice and working slices. This valve has such characteristics as compact structure, high working pressure, good performance, high reliability, etc The circuit is parallel connection. There are many spool functions for option. The positioning and returning modes of the valve include spring returning and detent control. There is a check valve inside the valve plate in case of back flow. There is a main relief valve in the inlet slice to control the whole system pressure. According to the customers’ requestes, the overload valve can be assembled on A, B port. The valve is widely used in such hydraulic systems of engineering machinery as forklift environmental trucks, etc.
